Basic Info.
Product Description
Packing Process:
1.Push box into star wheel.
2.Fold box lower small flap.
3.Press both lower big flaps.
4.Flatten both big flaps
5.Product fall into box.
6.Fold box upper small flap.
7.Press both upper big flaps.
8.Flatten both big flaps.
9.Product push out.
Product Specification
| Model No. | SN-120L |
| Production speed: | 20-50 box per min |
| Paper box's largest size | 200 x 80 x 80mm |
| Paper box's smallest size | 60 x 20 x 20 mm |
| Paper quality of carton | 250-350g/m3 |
| Motor horsepower | 1/4HP 15:1 1.5KW/H |
| Power supply | 220V 50/60HZ single phase |
| Machine noise | ≤80dB |
| Gas source | 0.5-0.8 Mpa |
| Compress air consumption | 260L/min |
| Machine measurement: | L 1100 x W 1500 x H 1700 mm |
| Machine weight | 450Kg |
Foshan Sayok Packaging Machinery Co.,Ltd., located in Foshan, Guangdong, is dedicated to developing and producing various packaging machinery. With advanced R & D concept, professional technology, mature processing system, rigorous QC management system and considerate after-sales service, we have won a good reputation in the industry. With rich industry knowledge and service experience, we can offer our clients one-stop packaging solutions. We welcome you to visit our factory, and talk about business face to face with us. We firmly believe that our rise in the industry can't be achieved without your support. We aim to produce more advanced products and co-advance with our clients.
Since we set up the company, we have developed dozens of packaging machines and corollary equipments in several series. From double frequency conversion packaging machine series to advanced three servo packaging machine, and then full-automatic packaging production line. After continuous improving and perfecting, our production techniques have reached industry standard, and thus helped us to win many distributors.
